CSC-003 Modern Lowboy

Overview

The CSC-003 Modern Lowboy is a masterclass in clean lines, timeless design, and functional craftsmanship. Featuring a balanced multi-drawer configuration and radiused corner details, this lowboy bridges classic case piece construction with contemporary aesthetics. Complete with comprehensive shop drawings, a full 53-item indexed cut list, and step-by-step assembly guides, this plan provides everything required to build a heirloom-quality piece.

Key Design Features

• Multi-Tiered Storage: Designed with a lower row of expansive drawers and a top row of three smaller divided drawers, offering versatile organization.

• Robust Framework: Built using a stable ladder-frame assembly method (Lower, Mid, and Upper frames) reinforced with center supports and pocket-screw joinery.

• Refined Detailing: Incorporates radiused top geometry, custom-sized drawer pulls, a front apron, and clean side panel insets.

Specifications & Dimensions

• Overall Dimensions: 50" Width × 26" Depth × 33" Height (approximate finished dimensions based on component sizing).

• Construction Materials: Utilizes 3/4" and 1" solid stock for primary visible components, 3/4" plywood for side panels, and 1/4" panels for drawer bottoms and the back panel.

• Total Components: 53 uniquely indexed parts mapped through an exploded reference drawing and 7 detailed assembly steps.
